| Features |
•>130lm/w.
•Universal AC input 100-277Vac or 200-480Vac
•Protections: Short circuit / Over current / Over temperature.
•Meanwell driver and Osram led chip.
•45 / 60 / 90 /120 degree option.
•Clear or diffused cover.
| Dimension |
| Specification data |
| Item No. | UFO-150W |
| Rated Power | 150W |
| Input Voltage | 100-277Vac or 200-480Vac. |
| Input Current | 2.0A / 115VAC ; 1.0A / 230VAC ; 0.75A / 277VAC |
| Power Factor | PF>0.95 |
| Power Efficiency | >93% |
| Beam Angle | 45 / 60 / 90 /120 degree |
| Lamp Base | Wires |
| LED Luminous Efficiency | >130lm/w |
| Luminous Flux | 19,500lm |
| Color Temperature Standard | 2,700k |
| 3,000 K | |
| 4,000 K | |
| 5,000K | |
| 5,700K | |
| Color Rendering Index(CRI) | Ra＞83 |
| LED Emitter Life | 50,000hours |
| Replacement | 300-400W MH, HPS |
| Diameter | Dia 340mm |
| Working Environment | Indoor lighting |
| Operating Temperature | -40~50℃ |
| Why us? |
| Microwave sensore + dimming |
| Light Distribution curve |
| Applications |
High/Low Bay Lighting/Sports Lighting/Factories Lighting
Other applications
| Certificate |
| The relevant product parameters |
| Item No. | Watts | Power Factor | Luminous Flux(130lm/w) | Replacement | Diameter | CRI |
| UFO-60W | 60W | PF>0.95 | 7,800lm | 175-250w MH, HPS | Dia 235mm | Ra>83 |
| UFO-100W | 100W | PF>0.95 | 13,000lm | 250-350w MH, HPS | Dia 280mm | Ra>83 |
| UFO-120W | 120W | PF>0.95 | 15,600lm | 300-350w MH, HPS | Dia 340mm | Ra>83 |
| UFO-150W | 150W | PF>0.95 | 19,500lm | 300-400W MH, HPS | Dia 340mm | Ra>83 |
| UFO-160W | 160w | PF>0.95 | 20,500lm | 350-450w MH, HPS | Dia 340mm | Ra>83 |
| UFO-200W | 200w | PF>0.95 | 26,000lm | 450-600w MH, HPS | Dia 400mm | Ra>83 |
| UFO-240W | 240W | PF>0.95 | 31,000lm | 600-750w MH, HPS | Dia 400mm | Ra>83 |
