| Rrtrofit LED Lighting |
Out with the old, in with the newest – the future of lighting is now.
LED retrofit lamps are direct replacements for conventional lamps.
LEDs deliver higher lumens per watt (lm/W) which means significant energy and cost savings while lasting
more than ten times longer than conventional sources.
With their directional light, instant on and ability to dim, LEDs are fast becoming the light source of choice.
| Product Features |
.Delivers >2500 lumens of light, 130lm/w or 150lm/w.
.Ideal for upgrading different lay-in fixtures to energy saving LEDs .
.Quick and easy transition to energy efficient LEDs.
.LED pathway retrofit kit use your existing lighting fixtures.
.Easy install.
| Technical Specifications |
| Rated Power | 20W |
| Universal AC input | 100-277Vac or 200-480Vac |
| Input Current | 0.64A / 115VAC ; 0.32A / 230VAC ; 0.3A / 277VAC |
| Power Factor | PF>0.95 |
| Power Efficiency | >88% |
| LED Luminous Efficiency | 130lm/w, 150lm/w |
| Luminous Flux(130lm/w) | 2,600lm |
| Luminous Flux(150lm/w) | 3,000lm |
| Color Temperature Standard | 3000k,4000k,4500k,5000k,5700k,6500k |
| Color Rendering Index(CRI) | Ra>83 |
| LED Emitter Life | >50,000hours |
| Replacement | 40W-60W HID,CFL |
| Working Environment | Indoor/Outdoor Lighting |
| Operating Temperature | -40~50℃ |
| Warranty | 5 years factory warranty |
| Applications |
.Use in new construction or retrofit applications
.Pathway fixture/Canopy fixture/ ceilings fixture
.Other applications
| The relevant product parameters |
| Item No. |
Watts
|
Power Factor
|
Luminous Flux(130lm/w)
|
Luminous Flux(150lm/w)
|
Replacement
|
CRI
|
| PW-20 |
20W
|
PF>0.95
|
2,600lm
|
3,000lm
|
40W-60W HID,CFL
|
Ra>83
|
| PW-30 | 30W | PF>0.95 | 3,900lm | 4,500lm | 75W-105W MH/HPS | Ra>83 |
| PW-40 | 40W | PF>0.95 | 5,200lm | 6,000lm | 125W-150W MH/HPS | Ra>83 |
| PW-60 | 60W | PF>0.95 | 7,800lm | 9,000lm | 175W-250W MH/HPS | Ra>83 |
