Description
Product Features

led lighting retrofits beam angle:120 degrees.
Special light design, IP54,widely applications.
Universal AC input / Full range(UP to 295VAC).
Protections: Short circuit / Over current/ Over temperature.
Wide colour availability in degrees Kelvin(K),2700-6700K.



Applications

High bay retrofit/ warehouse,factory.
Industrial lighting/ industry, major halls, supermarkets.
Gas station/ canopy lighting.
Other applications.



Technical Specifications
Rated Power 120W
Input Voltage 100-277VAC / 50-60Hz
Power Factor PF>0.95
Light Source Cree LED
CRI Ra>83
Luminous Flux 16200lm±10%
Replacement 350W-400W MetalHalide/HPS
Color Temperature Standard WarmWhite: 2,700-3,500 K
Natural White: 4,000-4,500 K
Cool White: 5,500-6,700K
Size(mm) 270*270*65mm/10.6"*10.6"*2.5"
LED Emitter Life 50,000hours



The relevant product parameters
Model NO.
Rated Power
350W
300W
240W
Light Source/Count

140pcs LED/Osram/
Cree LED chip

140pcs LED/Osram/
Cree LED chip
140pcs LED/Osram/
Cree LED chip
Luminous Flux
42000 lm±10%
36000 lm±10%
28800 lm±10%
Replacement
1000W-1350W MH/HPS
900W-1200W MH/HPS
600W-750W MH/HPS
Input Voltage 100-277VAC / 50-60Hz 100-277VAC / 50-60Hz 100-277VAC / 50-60Hz
Power Efficiency
>88%
>88%
>88%
Beam Angle
120°
120°
120°
Lamp Base
E40 / E39
E40 / E39
E40 / E39
LED Luminous Efficiency
>120lm/w
>120lm/w
>120lm/w
CRI
Ra>83
Ra>83
Ra>83
Dimensions
270*270*178mm
10.6*10.6*7inch
270*270*178mm
10.6*10.6*7inch
270*270*178mm
10.6*10.6*7inch
LED Emitter Life 50,000hours 50,000hours 50,000hours
Warranty
5 years factory warranty
5 years factory warranty
5 years factory warranty

Model NO. RK-150W RK-120W RK-100W RK-80W
Rated Power 150W 120W 100W 80W
Light Source/Count Osram/Cree LED chip Osram/Cree LED chip Osram/Cree LED chip Osram/Cree LED chip
Luminous Flux 20250lm±10% 16200lm±10% 13500lm±10% 10800lm±10%
Replacement 450W-500w MH/HPS 400W-450w MH/HPS 350W-400w MH/HPS 275W-300w MH/HPS
Input Voltage 100-277VAC / 50-60Hz 100-277VAC / 50-60Hz 100-277VAC / 50-60Hz 100-277VAC / 50-60Hz
Power Efficiency >88% >88% >88% >88%
Beam Angle 120° 120° 120° 120°
Lamp Base E40 / E39 E40 / E39 E40 / E39 E40 / E39
LED Luminous Efficiency >135lm/w >135lm/w >135lm/w >135lm/w
CRI Ra>83 Ra>83 Ra>83 Ra>83
Dimensions 280*170*62mm 280*170*62mm 280*170*62mm 280*170*62mm
LED Emitter Life 50,000hours 50,000hours 50,000hours 50,000hours
Warranty 5 years factory warranty 5 years factory warranty 5 years factory warranty 5 years factory warranty
